automatic or manul reset capillary phial gas oven thermostat 250V 16A used for boiler, BBQ, frier, watr heaters
Specifications
High Temperature Adjustable Capillary Thermostat
Expansive Temperature Controller for Electric Water Heater, Washer, boiler
High Temperature Adjustable Manual Reset Capillary Thermostat
Expansive Temperature Controller for Electric Water Heater, Washer, Electric Oven, Deep Fryer, Water Boiler etc.
Adjustable capillary thermostat.
Material:
- Stainless Steel: ø 3mm
- Copper: ø 5mm
Capillary length: min. 300mm
| Type | Operation Temperature ° C | Switch form | Max Temp of Sensor ° C | Capillary tube length(mm) | Puffing type |
| High Temp | Low Temp |
| OFF | DIFF | OFF | DIFF |
| WY30A-C | 30 ± 4 | 5 ± 3 | -30 ± 4 | 5 ± 3 | SPDT | 80 | 800 | L |
| WY75B-C | 75 ± 4 | 5 ± 4 | 30 ± 5 | 5 ± 4 | SPST | 120 | 500 | L |
| WY120C-C | 120 ± 5 | 6 ± 4 | 30 ± 6 | 6 ± 4 | SPDT | 150 | 1100 | L |
| WY190B-C | 190 ± 6 | 8 ± 4 | 30 ± 8 | 8 ± 4 | SPST | 250 | 400 | L |
| WY250B-C | 250 ± 10 | 10 ± 5 | 30 ± 12 | 10 ± 5 | SPDT | 300 | 900 | L |
| WY320A-C | 320 ± 12 | 10 ± 8 | 60 ± 15 | 10 ± 8 | SPDT | 400 | 800 | L |
Packaging & Delivery
| Packaging Detail: | white box and 200 pcs per carton |
| Delivery Detail: | 20 days on order date |
This is the most representative product, and most widely used among liquid-expanding products. Various specifications can be changed as the customers’ demands. Application - Fridge, freezer, hot and cool dispenser, air conditioner. - All sorts of cooking equipments such as fryers, electric oven, microwave, waffle maker, and so forth. - sauna, water bed, ATM machine MIN -30°C ~ MAX +320°C 120°C 20A/250VAC, 10A/380VAC Single Pole Double Throw (SPDT),Single Pole Single Throw (SPST) M4 fixed bracket (28mm from center to center) 90°, Straight 75g Stainless, Standard 1000mm (Optional 250mm ~ 2000mm) R type / B type (optional) PT1/4", M12, M14 (optional)
